340 Gpa Insulating 95% Alumina Ceramics Materials 3.6 g/cm³ Various Components Customized

Name: 340 Gpa Insulating 95 Alumina Ceramics Materials 36 gcm Various Components Customized
Brand: HENGYUAN
Price: 1 USD

340 Gpa Insulating 95% Alumina Ceramics Materials 3.6 g/cm³ Various Components Customized Manufactures

Brand Name : HENGYUAN

Model Number : 95% Alumina Ceramics

Certification : CE,UL

Place of Origin : WUXI JIANGSU CHINA

MOQ : 100

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 5000 PCS/WEEK

Delivery Time : 20 DAYS

Packaging Details : Carton

Material : 95% Alumina Ceramics

Color : White

Density : 3.6 g/cm³

Maximum Use Temperature : 1600 ℃

OEM，ODM : Acceptable

Orgin : WUXI JIANGSU CHINA

MOQ : 100 PCS

Package : Carton

Contact Now

Alumina ceramic(Al2O3), is an industrial ceramic that has high hardness, is long wearing, and can only be formed by diamond grinding.Because of its great performance,alumina ceramic is widely used in many fields.can meet the requirement of daily using and specifical features.

Features Of Alumina Ceramic :

1. Shape : customizable

2. Colour : white

3. High thermal conductivity

4. Good corrosion resistance

Naterial	Unit	A95% Alumina Ceramics	A97% Alumina Ceramics	A99% Alumina Ceramics	A99.7% Alumina Ceramics
Density	g/cm³	3.6	3.72	3.85	3.85
Flexural Strength	Mpa	290	300	350	350
Compressive Strength	Mpa	3300	3400	3600	3600
Modulus of Elasticity	Gpa	340	350	380	380
Impact Resistance	MPam1/2	3.9	4	5	5
Weibull Modulus	M	10	10	11	11
Vickers Hardulus	HV0.5	1800	1850	1900	1900
Thermal Expansion Coefficient	10-6K-1	5.0-8.3	5.0-8.3	5.4-8.3	5.4-8.3
Thermal Conductivity	W/Mk	23	24	27	27
Thermal Shock Resistance	△T℃	250	250	270	270
*Maximum Use Temperature	℃	1600	1600	1650	1650
Volume Resistivity at 20℃	Ω	≥1014	≥1014	≥1014	≥1014
Dielectric Strength	KV/mm	20	20	25	25
Dielectric constant	εr	10	10	10	10
